Click the Obs pin to link an observation to an area of the drawing. See Add Coordination Issues to a Drawing. Click the Issue pin to link a coordination issue to an area of the drawing. Click the Punch pin to link a punch item to an area of the drawing. See Add Punch List Items to a Drawing. Click the Photos pin to link a photo to an area of the drawing. For example, if your organization does not use the Coordination Issues tool, you will not see the 'Issue' pin in the markup toolbar. Note: You will only see pin markup options for the tools that are currently enabled in the project. Pins: Click to select different pin markups to link items to specific areas of the drawing. Hold the Shift key (to create a symmetrical circle), left-click and drag to the bottom right of the circle, and release the left-click. Tip! To draw a circle over the desired area, start at the upper-left corner where the edges of the left and top sides of the circle would meet. Drawing: Add a square or circle to add a link to another drawing sheet to. Distance / Area / Freehand / Calibrate: After adding a calibration to your drawing using the Calibration tool, use the other measuring tools to measure a distance, area, or curved or poly shape. Click and drag the corners of the text box if you want to adjust the size of the box. Text: Add a text box to add information or comments. Click inside the box to begin typing. You can adjust the font size by selecting a size number from the drop-down menu, and you can change the color and thickness of the line using the Color and Line Width options in the toolbar. Arrow / Line / Double Arrow: Draw a line or an arrow to point to an area or link an item to. Cloud / Box / Ellipse : Draw a shape to highlight an area or link an item to. See Link Related Items on a Drawing.
Tip! Hold the 'Shift' button on your keyboard if you want to draw a straight line. You can change the color and thickness of the line using the Color and Line Width options in the toolbar.
Pen / Highlight: Draw freehand shapes on the drawing using either Pen or Highlight. Select multiple markups to publish, edit, resize, or delete using the Multi Select or Lasso tools. Select / Multi / Lasso: Pan around the drawing by clicking and dragging on an image with the Select tool.
